8. Appendix 124
See related items in “Setting the Audio to Record” (page 46) and “User Menu” (page 70).
Audio Input (CH1&CH2)
The following shows the block diagram with the handle attached.
INPUT1
L
R
INPUT2
Shoe CH1
Shoe CH2
Internal MIC
CH1
[CH1 Input Select]
INPUT1
Internal MIC
Shoe CH1
[CH2 Input Select]
INPUT1
INPUT2
Internal MIC
Shoe CH2
For XLR adaptor
For XLR adaptor
<CH1 LEVEL
CONTROL>*
AUTO
MAN <CH1 INPUT LEVEL>
0 ~ 10
[CH1 Wind Filter]
On
Off
[CH2 Wind Filter]
On
Off
CH2
<CH2 LEVEL
CONTROL>*
AUTO
MAN <CH2 INPUT LEVEL>
0 ~ 10
[CH1&2 AGC Mode]
Mono
Stereo
[Color Bars]
[1kHz Tone on Color
Bars]
On
Off
[Audio Input Level]
0 ~ 99
[Limiter Mode]
Off, -6dB,
-9dB, -12dB,
-15dB, -17dB
SG
[CH1 Level]
Audio Input Level
Side
Level + Side
Through
[CH2 Level]
Audio Input Level
Side
Level + Side
Through
* Set to Manual when audio is input from XLR adaptor.
Block Diagrams
