2-3
ASUS VA27D Series LCD Monitor
2.3
Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
•
The recommended adjusting angle is +35˚ to -5˚ (for tilt)/+180˚ to -180˚ (for
swiveling by removing the stop screw)/ +150 mm (for height adjustment)/90˚
(for portrait view).
150mm
180°
180°
0°
-5°~+35°
(Tilt)
(Swivel)
(Height adjustment)
Pivoting the monitor
1. Lift the monitor to the highest position.
2. Tilt the monitor to its maximum angle.
3. Pivot the monitor to the angle you need.
0°
90°
-90°
0°
-5°~+35°
It is normal that the monitor slightly shakes while you adjust the viewing angle.
