Specifications 28 Apollo x16 Hardware Manual
ANALOG I/O
Line Inputs 1 – 16
Frequency Response 20 Hz – 20 kHz, ±0.05 dB
Dynamic Range 124 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 23 dBu) -115 dB (0.000180%)
Maximum Input Level (Reference Level @ +4 dBu) 24 dBu, Balanced
Maximum Input Level (Reference Level @ -10 dBV) 6.2 dBV (8.4 dBu), Balanced
Input Impedance 10k Ohms
Connector Type Two Female DB25, Tascam wiring
Line Outputs 1 – 16
Frequency Response 20 Hz – 20 kHz, ±0.02 dB
Dynamic Range 127 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS) -123 dB (0.000068%)
Maximum Output Level (Reference Level @ +4 dBu)
24 dBu (21.8 dBV)
Maximum Output Level (Reference Level @ -10 dBV) 10 dBV (12.2 dBu)
Output Impedance 100 Ohms
Connector Type Two Female DB25, Tascam wiring
Monitor Outputs 1 – 2
Frequency Response 20 Hz – 20 kHz, ±0.02 dB
Dynamic Range 133 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS) -129 dB (0.000037%)
Maximum Output Level (Reference Level @ +4 dBu)
24 dBu (21.8 dBV)
Maximum Output Level (Reference Level @ -10 dBV) 10 dBV (12.2 dBu)
Output Impedance 100 Ohms
Connector Type Balanced Male XLR (pin 2 hot)
DIGITAL I/O
AES/EBU
Connector Type XLR
Format IEC 60958 Type I
Word Clock
Connector Type BNC
Lock Range ±4% of any supported sample rate
Word Clock Input Termination 75 Ohms, switchable
Synchronization Sources
Internal, Word Clock, AES/EBU
(continued)
