VM-4H2 – EDID Acquisition Policy 8
EDID Acquisition Policy
This section describes the EDID policy as a function of the state of DIP-switch 4 (Lock Default
EDID).
When set to ON (down) , the input EDID is locked to the default EDID value.
When set to OFF (up) :
•
If no outputs are connected when powering on the VM-4H2 , the default EDID is set on
the input. The EDID of the first output that is connected after powering the device is set
to the input. This EDID is replaced by the default EDID only when all outputs are
disconnected.
•
If one or more outputs are already connected when powering on the VM-4H2 , the valid
EDID of the display that is connected to the output with the highest number is set to the
input (for example, if OUT 2 and OUT 4 are connected and both have valid EDIDs, when
powering the device, the EDID of the display connected to OUT 4 is written to the input).
DIP-switch changes take effect only after powering on the device.
