AverMedia Live Gamer Portable 2 Plus - Manual (Page 3)

3 / 91
1 Function Dial Switch among 3 functions: “ Capture / Stream ”, “ Media S har e ”, and “Settings”. ( → See page 04 )
2 Capture Mode Switch between 2 modes: Single Mode ( → See page 0 8 ), Multi Mode ( → See page 48 ).
3
Scene ( ※ when Multi Mode
is selected)
Select / add / delete scenes. ( → See page 55 )
4
Source ( ※ when Multi Mode
is selected)
Select / add / set / delete the Source (capture device, webcam , PC screen, video, image, text, w eb
pages, etc.). ( → See page 60 )
5 Preview Window Shows the video screen of the source.
6 Record / Stream Switch to “Record” or “Stream” to execute the recording / streaming settings.
7 Live Editing button Enable / disable the Live Editing function. ( ※ when Multi Mode is used) ( → See page 7 8 )
8 Capture Button
・ Start / s top r ecording / s treaming
・ Save Live Editing
・ Take a s napshot
9
Source Volume Adjustment
( → Se e page 1 6 )
・ Adjust the recording volume of the microphone sound, or turn the mute on / off
・ Adjust the recording volume of the source sound, or turn the mute on / off
・ Adjust the playing volume of the source sound, or turn the mute on / off
10
Audio Mixer
( → See page 1 8 )
Set the mixing of the source and microphone sound
11 Switch to the full screen view
12 Show the utilization rate of CPU and GPU, and the FPS value of the source
13
・ Switch between Lite Mode and Normal Mode
・ Minimize / maximize the window (full screen view) in the taskbar
・ Quit RECentral
2-1. Main Menu ( Multi Mode )
Chapter 2: Interface
