1 Capture Device Select or edit c apture device ( → See page 1 0 )
2 Record / Stream
3 Preview Window Show s the video screen of the source (capture device)
4 Time available for recording Time available for recording (calculated based on the free space of HDD)
5 Capture Button
・ Start / stop (save) the recording
・ Take a s napshot
6
Source Volume
Adjustment
( → See page 19 )
・ Adjust the recording volume of the microphone sound, or turn the mute on / off
・ Adjust the recording volume of the source sound, or turn the mute on / off
・ Adjust the playing volume of the source sound, or turn the mute on / off
7 Audio Mixer Set the mixing of the source and microphone sound ( → See page 1 8 )
8 Switch to the full screen view
9
Shows the loading of CPU and GPU, and FPS value of the source. You can check in the FPS view if " processing fai led " is taking place.
( → In case that FPS value is lower (worse) than the value in the specified quality, see page 1 1 . )
10
・ Switch between Lite Mode and Normal Mode
・ Minimize/ maximize the window (full screen view) to the taskbar
・ Quit RECentral
Chapter 3 ： Capture Mode: How to Use Single Mode
3-1. Main Menu in Single Mod e
・ Recording: Set Recording Q uality (resolution / FPS / bit rate, etc.), Codec (hardware / software
encoder) (→ See page 1 2 )
・ Streaming: Streaming Platform s et up , Q uality, Codec, etc. (→ See page 2 5 )
