15
CAUTION. Spiral spring. Risk of bruising. Insert and remove spiral spring carefully.
Keep fingers from getting caught in the spiral spring.
Notice. Coiled cables are blocked from radiation. Blocked radiation results in
reduced disinfection effect. Disinfect coiled cables additionally with disinfectant
solution.
3. Place microphones inside drawer with the
head of the microphone facing the marking
(Fig .3a and 3b).
Fig. 3b
4. Close the drawer until it clicks into place.
5. The display shows the main menu and the selection of disinfection time.
4.3 Inserting Headsets and Clip-on Microphones.
Use the cable tray and the spiral spring to insert small microphones. Cable tray and spiral spring are
available separately.
1. Put the cable tray onto the metal grille. (Fig. 4, 1 ). The cable tray is fixed magnetically.
2. Insert the spiral spring in the area of the first cross bar
(Fig. 4, 2 ).
Fig. 4
Fig. 3a
