Getting Connected
Outputs
Connecting individual audio outputs:
You can connect the audio output from each side independently to a mixer (such as a DJ mixer). This
allows the SDR-4000 to be used as a dual USB/SD player used in conjunction with DJ-style mixers with a
crossfader.
1) Using a stereo RCA to RCA cable or two XLR-F to XLR-M cables, connect one end to the audio outputs
of side A on the SDR-4000. Connect the other end to available inputs on the mixer.
2) Repeat above with the output from side B.
Connecting audio output from the toggled output:
The toggled output allows you to toggle between side A and side B audio from one set of jacks. The toggle
on the front panel is used to select the output.
1) Using a stereo RCA to RCA cable, connect one end to the toggled audio output on the SDR-4000.
Connect the other end to an available input on your mixer or amplifier.
