Features
1. POWER button – Use this button to turn the unit ON/OFF.
2. REC LEVEL knob – Use this knob to increase/decrease the recording level.
(see page 16 for instructions on recording)
3. USB LED – Indicates USB is selected for playback/recording.
4. SD LED – Indicates SD is selected for playback/recording.
5. REC LEVEL LEDs - Use these LEDs to monitor and achieve an optimal recording level. (See
Operations section for information on setting recording level)
6. LCD display – Displays system information, current operations and settings.
7. SD CARD slot – Insert SD slot for recording and playback.
8. USB port – Insert USB thumb-drive for recording and playback.
9. DELETE button – Use this button to delete a file. (See Operations section for instructions on
deleting a file)
10. FOLDER button – Use this button to toggle through different folders. (See Operations section
for instructions on browsing folders)
11. +10 button – Use this button to advance 10 tracks at a time.
12. REPEAT button – Use this button to enter a repeat playback mode. (see Operations section
for instructions on repeat playback mode)
13. SINGLE button – Use this button to enter single playback mode. (see Operations section for
instructions on repeat playback mode)
3
4
5
6
7
8
9
12
20
13 14
10 11
1
2
15
16
17 18 19
21
22
Front Panel:
