Smart-UPS On-Line Step-Down Transformer SRT5KRMTF 3
Specifications
For additional specifications refer to the APC by Schneider Electric web site, www.apc.com .
Environmental
Physical
Electrical
Operation above the input voltage range may cause equipment damage.
Operation below the input voltage range may cause overload or automatic shutdown. When connecting directly to a
branch circuit, check that the line voltage is within specifications. When connecting to the UPS, check that the line
voltage into the UPS is within specifications before transferring to bypass mode.
Temperature
Operating 0º to 40º C (32º to 104º F)
Storage -15º to 45º C (5º to 113º F)
Maximum Elevation
Operating 0 - 3,000 m (0 - 10,000 ft)
Storage 0 - 15,000 m (50,000 ft)
Humidity 0% to 95% relative humidity, non-condensing
Protection Class IP 20 rating
Lifting guidelines 32 - 55 kg (70 - 120lb)
Unit weight, without packaging 54.6 kg (120 lb)
Unit weight, with packaging 63.6 kg (140 lb)
Unit dimensions without packaging
Height x Width x Depth 130 mm x 432 mm x 719.4 mm
5 in x 17 in x 28.3 in
Unit dimensions with packaging
Height x Width x Depth 330 mm x 610 mm x 960 mm
13 in x 24 in x 37.8 in
The model and serial numbers are on a small label located on the rear panel.
Installation With Line Cord
Nominal Input Voltage (Vac) 208 Vac
Nominal Output Voltage (Vac) 120 Vac
Input Voltage Range (Vac) 185 - 230 Vac *
Input Current Rating 24 A
Line Frequency (Hz) 50/60 Hz
Efficiency 90-95%
Maximum Input Power 5000 VA
Maximum Output Power (VA) 4500 VA
*For continuous operation below Vin = 205 Vac, the output load must be reduced to limit
the maximum input current to the amount specified above. Continuous operation above
the maximum specified input current may cause the unit to overheat and shut down.
Contact APC by Schneider Electric for additional information.
Input Power Distribution 3 ft cord with L6-30P
Output Power Distribution (2) 15 A circuits with (4) 5-20R and (2) 15 A circuits with (2) 5-20R
