288 - User's Manual
HDD Max. Capacit y *Please ref er to the HDD supported list on t he VIVOTEK website.
RAI D RAID 0, 1, 5, 6, 10
Disk Management Create, f ormat and remov e disk
Manual Backup
USB Dongle (FAT Format )
NAS (SMB & CIFS)
Schedule Backup NAS (SMB & CIFS)
Playback
Play back Display
64 Channels (the max. number of monitors support ed depends on t he decoding capabilit y
of y our sy st em)
Equal: 1x1, 2x2, 3x3, 4x4, 5x5, 6x6, 7x7, 8x8
Panorama: 1P+6, 2P, 2P+3, 3P
Focus: 1+12, 1+16, 1+3, 1+5, 1+7, 1+9, 2+8
Vert ical: 1V+6, 2V+2, 2V+3, 3V, 3V+4, 4V, 4V+4, 5V
Single lay out display, f ull screen display
Custom lay out, lay out rot at ion
Play back Control Play, rewind, pause, st op, next / prev ious f rame, 1/64X ~ 64X speed control, bookmark
Video Search
Calendar, ev ent, alarm, bookmark, thumbnail, Smart Search I I, transact ion (POS), Data
Magnet, log
Snapshot BMP & JPEG
Video Clip Export 3GP & EXE
Network
Et hernet 10/100/ 1000Mbps Et hernet (RJ-45) x2
Video Throughput f or Remot e Client 400 Mbps
Prot ocols
IPv 4, TCP/ IP, HTTP, HTTPS, UPnP, RTSP/ RTP/ RTCP, SMTP, FTP, DHCP, NTP, DNS,
DDNS, IP Filter
Alarm Management
Alarm Period (sec.) Max. 30
Alarm Filt er Time, trigger ty pe (camera/substat ion/sy stem), status, name, t rigger source
Alarm Set ting
Realtime sy stem not if icat ion
Alarm result display by list or thumbnail
Schedule Ty pe Cont inuous, schedule, manual
Camera Ev ent
General:
motion det ection, camera DI, camera DO, I R (inf rared), PI R (passiv e inf rared),
tampering det ect ion, temperature, camera disconnect ed, recording error, st op recording,
v ideo loss (v ideo serv er only ), SD card lif e expect ancy detect ion, audio det ection,
shock detection
Smart VCA:
int rusion det ection, l oitering detect ion, line crossing det ect ion, unat tended object
detection, missing object detection, f ace det ection
Smart 360 VCA:
intrusion detection, crowd det ection, loit ering detect ion
Trend Micro IoT Securit y :
brute f orce att ack, cy beratt ack, quarant ine ev ent
Substation
ND Series NVR:
f an status, network disconnected, storage f ailure, st orage f ull, number of remaining
people, brut e f orce att ack, cy beratt ack, quarant ine ev ent
NR Series NVR:
net work disconnected, st orage f ailure, st orage f ull
NV Series NVR:
abnormal G-sensor mot ion, speeding, GPS disconnect ed
External Dev ices Ev ent DI/ O (with I/ O box), TCP message
Act ion
St art t o record v ideos, set DO stat us, go t o camera presets, send HTTP request s, send
liv e streaming, send email with snapshot of assigned camera(s), go t o eMap, sound t he
alarm and add bookmark
Alarm Stat e f or Management New, in progress, f alse alarm and close
Alarm Result Export .csv f ile
eMap
Source Import pict ure & f older
Dev ice Camera, ext ernal DI/ O
Marked Add, remov e, direct ion control, PTZ control, FOV cont rol, liv e v iew & play back
Ev ent Notif ication One or more liv e st reaming
External Interface
