BUILT-IN OVEN SAFETY
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
INSTALLATION REQUIREMENTS
Gather the required tools and parts before starting installation.
Read and follow the instructions provided.
IMPORTANT:
Observe all governing codes and ordinances.
NOTE:
Refer to the following “Location Requirements” and the
“Location Requirements” section of the Installation Instructions
provided with your built-in oven.
■
Cabinet opening dimensions that are shown must be used.
Given dimensions provide minimum clearance with oven.
■
Recessed installation area must provide complete
enclosure around the recessed portion of the oven.
■
Oven support surface must be solid, level, and flush with
bottom of cabinet cutout.
■
Floor must be able to support a single oven weight of
129 lbs (59 kg) for 27" (68.6 cm) models or 154 lbs (70 kg)
for 30" (76.2 cm) models.
■
Floor must be able to support a double oven weight of
251 lbs (114 kg) for 27" (68.6 cm) models or 288 lbs
(131 kg) for 30" (76.2 cm) models.
IMPORTANT:
To avoid damage to your cabinets, check with
your builder or cabinet supplier to make sure that the materials
used will not discolor, delaminate, or sustain other damage. This
oven has been designed in accordance with the requirements
of UL and CSA International and complies with the maximum
allowable wood cabinet temperatures of 194°F (90°C).
Tools and Parts
Parts Supplied
■
Deflector bracket
■
Plastic spacers - (4) single ovens, (6) double ovens
■
#8-18x
1
⁄
4
" screws - (2) for 27" (68.6 cm) models); (4) for 30"
(76.2 cm) models
Tools Needed
■
Phillips screwdriver
■
Measuring tape
■
Drill (for wall cabinet installations)
■
1
⁄
8
" (3 mm) drill bit (for wall cabinet installations)
■
Level
■
Flat-blade screwdriver
Parts Supplied With Your Built-In Oven
■
#8-14 x 1" screws - (2) single ovens, (4) double ovens
included with built-in oven
■
(2) #8-18 x
3
⁄
8
" screws - bottom vent included with
built-in oven
■
(4) #8-18 x
3
⁄
8
" screws - included with built-in oven
■
Bottom vent included with built-in oven
■
(2) Feet double oven included with built-in oven
■
(2) Front feet double oven included with built-in oven
