7
Positioning Oven Feet
Single Ovens
The positioning of the oven feet allow a single oven to be
installed in a recommended cutout height of 28 1 ⁄
2
" (72.4 cm).
Refer and adhere to the “Make Electrical Connection” section
in the Installation Instructions provided with your built-in oven.
Double Ovens
The oven feet allow a double oven to be installed in a
recommended cutout height of 51 7 ⁄
16
" (130.6 cm).
NOTE: Do not remove the spacers.
A
A
A. Spacers
1. Using 2 or more people, place the oven on its back on a
covered surface.
2. Install a foot on the left rear spacer using a #8-18 x 3 ⁄
8
"
screw.
NOTE: Position the foot so the long side of the foot is facing
toward the top of the oven.
A. Spacer
B. Foot
C. #8-18 x 3 ⁄
8 " screw
3. In the same manner, install a foot on the right rear of
the oven.
4. Install a front foot on the left front spacer using a #8-18 x 3 ⁄
8
"
screw.
NOTE: Position the foot so the long side of the foot is
facing toward the inside of the oven.
A. Front foot
B. #8-18 x 3 ⁄
8 " screw
C. Spacer
A
B
C
A
B
C
Oven Front Frame
