ENGINEERED APPLICATIONS
SureCross™ Configured Kit
This application employs two NAMUR proximity sensors that interface with the FlexPower Node. Based on the power consumptive properties of
the sensors and the required sample interval of 250 milliseconds it was calculated that the DX81 FlexPower supply would last one year. Banner is
continuously building a library of characterized sensors from different manufacturers to make FlexPower solutions plug-and-play.
SureCross ™ Configuration: Engineered Your Way
• Configured Kits are only a starting point; add Nodes through the configurable Gateway to
expand an application solution.
• Custom setup of I/O function, timing and network health monitoring is handled through a
configurable Gateway.
Modify
Alter Presets
Expand Configuration
FlexPower™ Settings
Custom Solution
SureCross ™ Unlimited Solutions.
Whatever the demands of your application,
configurable Gateways and Nodes can be set
to solve your most challenging remote sensing
scenarios. Configuration allows the assembly
of wireless networks using the exact SureCross
components required.
SureCross ™ Configured Kits.
Banner offers a large number of SureCross
wireless kits that are configured with
everything you need to solve many
common applications quickly and easily.
Preset functionality makes the network
easy to deploy and operate.
APPLICATION
SureCross ™ Method Cable Method
Junction Box
Control Panel
18'
Robot Work Cell
To Robot’s
Sensors
DX80 GATEWAY
Control Panel
Junction Box
DX80 NODE
DX81
Battery Box
Robot Work Cell
To Robot’s
Sensors
