More information online at bannerengineering.com
Sensors
Optimized for
use with
FlexPower™
Systems
Model Number Supply Voltage Description Sensing Mode Range Output Type Connection Data Sheet*
QT50ULBQ6-75390
FlexPower™
U-GAGE ® Ultrasonic 200 mm - 8 m
Selectable:
0 to 10V dc or
4 to 20 mA
5-pin
Euro QD
70137
SM312LPQD-76885
MINI-BEAM ® Photoelectric
POLAR RETRO
P 3 m
Bipolar
NPN/PNP
4-pin
Euro QD
69943
SM312DQD-75904
DIFFUSE
380 mm
Bipolar
NPN/PNP
4-pin
Euro QD
* Data sheets are for standard product, contact factory for additional supporting literature.
Model Number Construction Connection LED Function Inputs Data Sheet
M18GRY2PQ
18 mm mount
Nickel-plated brass
4-pin Euro QD
Choose Red, Yellow
or Green ON, flashing
or alternating
Other Colors
Available
PNP 121902
T30GRY2PQ
30 mm mount
Thermoplastic polyester
K50LGRY2PQ
30 mm mount
Thermoplastic polyester
K80LGRY2PQ
Flat or DIN mount
Thermoplastic polyester
Model Number Voltage Supplied Description Connection Housing Data Sheet
DX81 FlexPower Battery
Module to supply
FlexPower Node
Module driven by one lithium primary battery**
5-pin Euro QD IP67
131596
DX121 Module driven by six lithium primary batteries** 131628
**Replacement lithium primary battery model number is BWA-BATT-001
Model Number Voltage Supplied Description Connection Housing Data Sheet
SPS101Q
12V dc @ 120 mA max
Converts 105 - 130V ac, 60 Hz to 12V dc
(SPST e/m Relay Output)
Sensor Connection:
5-pin Euro QD
AC Power Connection:
5-pin Mini QD
IP54 66959
SPS101SQ
Converts 105 - 130V ac, 60 Hz to 12V dc
(Optically Isolated SPST Solid-state Output)
EZAC-E-QE5-QS5 24V dc @ 700 mA
Converts 100 - 230V ac to 24V dc
(no output)
IP65 120321
PS24W 24V dc @ 500 mA
Converts 100 - 240V ac to 24V dc
North America (wall plug)
5-pin Euro QD
Non-
industrial
(not sealed)
–
Model Number I/O Functionality Description Housing Data Sheet
DX85-4P4M2M2
2 Analog IN, 2 Analog OUT (0-20 mA);
4 Discrete IN (sourcing),
4 Discrete OUT (sourcing)
Modbus RTU Slave
Expansion I/O Modules;
used to expand Gateway
I/O capacity
IP67
131629
DX85-6P6
6 Discrete IN (sourcing),
6 Discrete OUT (sourcing)
131599
EZ-LIGHT ™
Indicators
Multi-Color,
7-function
Expandable
Remote I/O
FlexPower ™
Supplies
SureCross ™ Accessories
T30
M18
K50L
QT50U
MINI-BEAM
DX81
DX85
AC Power
Supply
Options
EZAC
K80L
