4–6 Chapter 4: Functional Description
Signals
Asynchronous Serial Interface (ASI) MegaCore Function User Guide January 2014 Altera Corporation
rx_ts_status[7:0] Output
TS status bits.
0 indicates receiver data valid
1 indicates start of packet
2 indicates end of packet
3 indicates receiver error
5:4 indicates 00 is unlocked; 01 is 204 byte packet lock, 11 is 188
byte packet lock
6 indicates TS serial polarity
7 indicates that the data on rx_data[7:0] is a valid word from the
8B10B decoder. Unlike rx_ts_status[0], this signal is not
dependent on the correct packet or synchronization structure of the
stream.
tx_protocol_out[9:0] Output
Output from transmitter protocol block for split
protocol/transceiver mode.
Notes for Table 4–1 :
(1) This signal is available for Stratix IV transceivers only.
(2) In Quartus II version 8.1 and later, the Stratix IV transceivers need RX buffer calibration through an altgx_reconfig (DPRIO) controller. You
must connect the ports to the altgx_reconfig controller externally. For further information on the RX buffer calibration, refer to Stratix IV
DPRIO documentation. If you are using Quartus II software version 13.1, upgrade the ASI MegaCore function to version 13.1 as well.
Table 4–1. Signals (Part 2 of 2)
Signal Direction Description
