Page 297
X
Open the hood.
X
Use a dry cloth to remove any moisture
from the fuse box.
X
To open: open clamps ;.
X
Fold up cover : in the direction of the
arrow and remove it.
X
To close: check whether the seal is seated
correctly in cover :.
X
Insert cover : at the back into openings
= on the fuse box.
X
Fold down cover :.
X
Hook clamps ; into the fuse box and
close.
X
Close the hood.
Fuse box in the front-passenger
footwell
X
To open: remove the floormat from the
front-passenger side.
X
Fold out perforated floor covering : in the
direction of the arrow.
X
To release cover =, press retaining
clamp ;.
X
Fold out cover = in the direction of the
arrow to the catch.
X
Remove cover = forwards.
i
Fuse allocation chart ? is located on the
lower right-hand side of cover =.
X
To close: insert cover = on the left-hand
side of the fuse box into the retainer.
Cover = engages in the retainers.
X
Fold down cover = until clamps ; lock
audibly.
X
Fold back perforated floor covering :.
