The HomeLink ா Universal Transceiver provides a
convenient way to consolidate the functions of up
to three individual hand-held transmitters into
one built-in device.
HomeLink
ா Universal Transceiver:
● Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and se-
curity systems.
● Is powered by your vehicle’s battery. No
separate batteries are required. If the vehi-
cle’s battery is discharged or is discon-
nected, HomeLink ா will retain all program-
ming.
Once the HomeLink ா Universal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink
ா Universal Transceiver buttons
should be erased for security purposes. For
additional information refer to “Program-
ming HomeLink
ா” later in this section.
WARNING
● Do not use the HomeLinkா Universal
Transceiver with any garage door
opener that lacks safety stop and re-
verse features as required by federal
safety standards. (These standards be-
came effective for opener models
manufactured after April 1, 1982). A ga-
rage door opener which cannot detect
an object in the path of a closing garage
door and then automatically stop and
reverse, does not meet current federal
safety standards. Using a garage door
opener without these features in-
creases the risk of serious injury or
death.
● During the programming procedure
your garage door or security gate will
open and close (if the transmitter is
within range). Make sure that people or
objects are clear of the garage door,
gate, etc. that you are programming.
● Your vehicle’s engine should be turned
off while programming the HomeLink ா
Universal Transceiver.
PROGRAMMING HOMELINK ா
1. To begin, press and hold the two outer
HomeLink ா buttons (to clear the memory)
until the indicator light
᭺
1 blinks (after 20
seconds). Release both buttons.
2. Position the end of the hand-held transmitter
1 - 3 inches (26 - 76 mm) away from the
HomeLink ா surface.
WIC0986
HOMELINK ா UNIVERSAL
TRANSCEIVER (if so equipped)
Instruments and controls 2-57
