INSTALLATION:
1. Connect a HDMI TM or DVI source (e.g., a Blu-ray Disc player) to the Transmitting Module.
2. Connect a HDMI TM or DVI display (e.g., a HDTV) to the Receiving Module.
3. Connect two solid Cat-5/5e/6 UTP/STP cable between the Transmitting and Receiving Modules.
4. Make sure these two solid Cat-5/5e/6 UTP/STP cable are tightly connected and not loose.
5. If you want to control the source devices at display side, plug in the IR blaster to the Transmitting Module and the
IR receiver to the Receiver Unit. If you want to control the display at source side, plug in the IR receiver to the
Transmitting Module and the IR blaster to the Receiving Module.
6. Plug in the 5V DC power supply unit to the latch-locking power jack on either the Sender Unit or the Receiver Unit.
7. If you see flickering or blinking image on the display, adjust the rotary control switch to improve the cable skew.
MAX stands for the strongest HDMI TM signal level for longest possible transmission length while MIN stands for
the weakest HDMI TM signal level for short transmission length. Try adjusting the signal level from MIN to MAX to
find the optimal setting for the HDMI TM over CAT5 transmission.
