INTRODUCTION:
Atlona Technologies AT-HD-BIR40SR HDMI TM v1.3 Extender with Bi-directional IR boosts your audio/video
transmission distance up to 200ft (60m) in HDTV 1080i format, 130ft (40m) in HDTV 1080p format, and 65ft (20m)
in HDTV 1080p with 36 bit color depth. With two cost effective solid Cat-5/5e/6 UTP/STP cable, users can readily
extend HDTV sources from DVD players, Blu-ray Disc player, PS3, PC, and any other kinds of sources compliant
with TMDS to distant display monitors including HDMI TM or DVI enabled TV sets or LCD PC monitors. The AT-HD-
BIR40SR also features with embedded IR input and output on both sender and receiver units so users can control
the source device or HDMI TM display at romote site via IR remote in di-directional IR pass-through.
The AT-HD-BIR40SR includes two units: Sender unit and Receiver unit. The Sender unit sends the HDMI TM or DVI
signals received from the source device and receives IR signals from the Receiver unit or sends the received IR
signal from the Sender unit via two low cost Cat-5/5e/6 cables. The Receiver unit is responsible for equalizing the
audio/video data received from the sender unit and sends the IR signals received from the IR receiver to the Sender
unit or receives IR signals from the sender unit . The transmission distance between the audio/video source and the
display can be up to 60m / 200ft under HD resolution (720p/1080i), or 40m / 130ft under Full HD resolution (1080p).
With 8-level digital signal equalization control on the receiver unit, users can adjust the signal level equalization scale
to the received audio/video signals, and therefore optimize the transmission distance between source and display.
FEATURES:
• HDMI TM 1.3c and HDCP compliant
• Extends the transmission length up to 200ft (60m) from the HDMI TM sources under HD resolution (1080i or 720p at
24-bit color depth)
• Extends the transmission length up to 130ft (40m) from the HDMI TM sources under Full HD resolution (1080p at 24-
bit color depth)
• Extends the transmission length up to 65ft (20m) from the HDMI TM sources under Full HD resolution (1080p at 36-
bit color depth)
• Minimizes the cable skew by adjustable 8-level equalization rotary control
• Supports half-duplex bi-directional IR pass-through
• Supports full frequency of IR signals from 20kHz to 60kHz
• Purely unaltered uncompressed 7.1ch digital HDMI TM over CAT5/6 cable transmission
• Wall mounting housing design for easy and robust installation
The length depends on the characteristics and quality of the cables. Higher resolutions and longer transmission
distances require low skew cables (<25ns/100m) for best performance.
