3�- UNIT INSTALLATION
3.1.- PRELIMINARY RECOMMENDATIONS
In order to use the unit safely, it is critical that individuals who handle it follow
the safety measures set out in the standards of the country where it is being
used, use the personal protective equipment necessary, and pay attention to the
various warnings indicated in this instruction manual.
The CMBUS unit must be installed by authorised and qualified staff.
The power supply plug must be disconnected and measuring systems switched off before
handling, altering the connections or replacing the unit. It is dangerous to handle the unit while
it is powered.
Also, it is critical to keep the cables in perfect condition to avoid accidents, personal injury and
damage to installations.
The manufacturer of the unit is not responsible for any damages resulting from failure by the
user or installer to heed the warnings and/or recommendations set out in this manual, nor for
damages resulting from the use of products or accessories that did not come with the unit or
that were made by other manufacturers.
Disconnect the unit from the power supply (unit and measuring system power
supply) before maintaining, repairing or handling the unit's connections.
Please contact the after-sales service if you suspect that there is an operational
fault in the unit.
3.2.- INSTALLATION
Do not use the unit until it is fully installed.
The unit is installed on a 35 mm DIN rail (EN 50022).
To install the unit on a DIN rail ( Figure 2) :
1�- Hook the rear clip of the unit to the top of the DIN rail.
2�- Pull the clip downwards.
3�- Push the unit into place on the DIN rail and release the clip.
