Info MENU
- Model, H/W Version, FPGA,F/W Release, Operating Time,
Cal. ID
Input Support Mode
Support Signals
Items Specifications
Supported
Signals
Serial Digital Interface
HD SDI- 2.970Gbps
SD HDI- 270Mbps
HDMI
DVI-I (DVI+VGA_IN)
H Frequency Range : 20~82 kHz
V Frequency Range : 55 ~ 90 Hz
Maximum resolution :1920x1080 60Hz
Maximum pixel rate : 162 MHz
DTV mode support : 720P, 1080i, 1080p
ANALOG RGB
H Frequency Range : 20~82 kHz
V Frequency Range : 55 ~ 90 Hz
Maximum resolution : 1920x1080 60Hz
Maximum pixel rate : 162 MHz
DTV mode support: 720P/1080i/1080p
SOG sync support
ANALOG Component
(DTV/DVD)
1080p/1080i/720P/480i/576i/480P/576P
CVBS NTSC/PAL/SECAM
Support Timings
 SDI Input
SMPTE-428.1M 2048x1080P(24/25)
SMPTE-425M(3G) 1920x1080P(50/60)
SMPTE-260M 1920x1035i(60/59.94)
SMPTE-259M 1920x1080i(50)
SMPTE-274M
1920x1080i (50/59.94/60)
1920x1080P (30Psf/25Psf/24Psf/30/25/24)
SMPTE-296M 1280x720P (24/25/30/50/59.94/60)
SMPTE-125M 480i(59.94)
ITU-R BT.601 576i(50)
