Page 24
9.17.075
Bronkhorst Cori-Tech BV
24
10
Troubleshooting
Symptom
Possible cause
Action
Suddenly a wrong value will be dosed
among a sequence of right values
when using on-off dosing with shut-off
valves.
(Back) pressure waves caused at
valve closing with high force might
give erratic reading at (mini) CORI-
FLOW.
Sudden pressure in- or decrease.
Select a different valve type
Make sure to have some volume or
dampener between valve and meter
Monitor ‘hardware error’ at alarm info
byte at instrument interface to indicate
this
Monitor ‘counter value’ at instrument
interface to detect this
Check inlet pressure
Even when dosing time is very short
flow signal is too slow
Filter settings might be not optimal.
Exponential smoothing filter value
probably too low.
Change exponential smoothing filter
setting. See section 5.
Large deviation on sequential batches
Filter settings might be not optimal.
Exponential smoothing filter value
probably too high.
Change exponential smoothing filter
setting. See section 5.
Supply pressure not stable
Check and stabilize pressure
Controller settings not optimal
Increase control stability by optimizing
PID settings.
Flow signal is >130%
Pressure too high
Lower the supply pressure
Resistance of flow line too low
Restrict the flow by using a manual valve
PID-Kp too high
Select a lower Kp value
FS value (capacity) too low
Increase the FS (capacity) value
Dosed value is not accurate enough
Flow meter has wrong zero point
Perform new auto-zero
Too many gas bubbles in liquid
Purge the flow meter
Vibrations disturbing the meter
Follow instructions for mounting
Flow signal >130%
Try to limit flow signal < 130%
Dosing time is too short
Increase dosing time
Proportional dosing is too fast
Adjust counter control gain to ensure
last part of dosing at 2%
Counter control gain too low
(Dosing too long at low flow)
Increase counter control gain to dose
longer at high flow (more accurate)
Reference instrument to check with is
not a weighing scale (e.g. volumetric
device)
Use a weighing scale and handle it
according to the instructions
Proportional dosing @2% gives too much
overshoot
Lower flow rate (dosing speed) or enable
overrun correction
Air in the system causes drifting
Try to purge the air out of the system
