Limitorque QX Electronic Actuator FCD LMENIM3314-00 – 5/11
flowserve.com
EMC - Electromagnetic Compatibility (EMC) and Electromagnetic Interference (EMI) standards to which this actuator
complies:
APPLICABLE
EMISSIONS
STANDARDS
EN50011:1998
CLASS A SERVICE
Radiated emissions
EN55011:1998 &
FCC Part 15, subpart J
30-130MHz
40dBmV / m
230-1000MHz
47dBmV / m
Conducted emissions
EN55011:1998 &
FCC Part 15, subpart J
0.15 to 0.5MHz
79dBmV (QuasiPeak 66dBmV avg)
0.5 to 30MHz
73dBmV (QuasiPeak 66dBmV avg)
Applicable immunity
standards
IEC EN 6100-6-1:2001
ESD
IEC6100-4-1:1995
+_8kV thru air
+_4kV thru contact
Radiated RF
immunity
IEC6100-4-3:1995
80MHz to 2GHz
10Vrms / m
Fast tansients/burst
IEC6100-4-4:1995
EFT
AC Power leads +_2kV
Signal leads: +_1kV
Voltage surges
IEC6100-4-5:2001
AC Power: +_2kV com, +_1kV diff
Signal leads: +_0.5kV com, +_1kV diff
Perf criterion: B
Conducted RF
immunity
IEC6100-4-6:1996
150kHz to 80MHz
10Vrms
Perf criterion: A w/80% AM
modulation @1KHz
Magnetic field
immunity
IEC6100-4-8:1993
Power line frequency
30A/m @60Hz
Perf criterion: A
Voltage dips and
interrupts
IEC6326-1:2005
(IEC61000-4-11:2004)
60Hz
100% dip, 1 cycle duration
40% dip, 10 cycle duration
70% dip, 25 cycle duration
100% dip, 1 cycle duration
Perf criterion: B, C
3 test each @ 10 sec interval
3 test each @ 10 sec interval
3 test each @ 10 sec interval
3 test each @ 10 sec interval
Notified Body
FM Approvals Limited
1 Windsor Dials
Windsor UK
Certification Number
FM09ATEX0058X”
IECEx
IEC 60079-0:2007
IEC 60079-1:2007
IEC 60079-7:2006
IEC 60529:1989 + A1:1999
Manufacturer’s Name
Limitorque, a division of Flowserve Corporation
Manufacturer’s Address
5114 Woodall Road
Lynchburg, VA 24502
Importer’s Name
Limitorque International
Importer’s Address
