Install the detergent dispenser and rinse injector sys-
tems in an easily accessible location, above the operat-
ing level of the wash tank. A fresh water feed tube may
be connected from the dishwasher wash tank fill piping
to the water inlet of the detergent controller. See figure
8-15 for an example. As required, make connections
between the detergent controller and the detergent res-
ervoir. Any detergent discharge tubing should enter the
machine at an elevation above the wash tank.
Connect the feed tube from the rinse injector pump out-
let to the tee on the final hot rinse piping. See figure 8-
15 for an example.
For electric booster heaters only, install separate 440
volt power wires between a circuit breaker in the ship's
local distribution panel and the 440 volt connections in-
side the booster main cover panel.
Install the power and control wires between the electrical
control enclosure and the junction box on the dish-
washer. Numbered terminals are provided in each en-
closure for all wires. See figure 8-13 (electric heated
machines) or figure 8-14 (steam heated machines).
Connect the detergent dispenser controller to an appro-
priate source of power. 24 vac terminals (1 amp max)
are available in the electrical control enclosure for dis-
pensers operating on 24 vac. Figure 8-12 identifies
these terminals. Voltage is present when the wash
pump operates. Also connect the probe (on the bottom
of the wash tank) to the controller.
Connect the rinse injector to an appropriate source of
power. 24 vac terminals (1 amp max) are available in
the electrical control enclosure for injectors operating on
24 vac. Voltage is present when the final rinse oper-
ates. Figure 8-12 identifies these terminals.
For machines with the optional power unloader, connect
the wires and conduit (separated for shipment) between
the machine and the junction box on the unloader.
þ
NOTE:
Power requirements for the dishwasher and
heaters are listed in Table 1-1.
WARNING:
Dangerous voltages are present on
connections to the electrical control
enclosure and electric booster heater.
Observe normal safety precautions for
high voltage electrical equipment
when connecting to the local distribu-
tion system. All work should be done
by a qualified electrician.
!
þ
NOTE:
Mounting hardware for the electrical control
enclosure and the electrical power cables from
the electrical control enclosure and electric
booster heater to the ship's local distribution
panel are to be furnished by the installing
activity.
Electrical.
Install the electrical control enclosure on a bulkhead ad-
jacent to the dishwasher. Controls should be easily ac-
cessible by the operator.
Install the 440 volt power wires between a circuit
breaker in the ship's local distribution panel and the
dishwasher electrical control enclosure. Separate ser-
vices are required for:
1. Power for motors and controls.
2. Power for electric wash tank heaters.
3. Power for electric rinse tank heaters.
