108
SYSTEM SETUP
Setting items Setting details
Distance
Set distance from listening
position to speakers.
Measure beforehand the
distance from the listening
position to each speaker. Unit : Set the unit of distance.
• Feet / Meters
Step : Set the minimum variable width of the distance.
• 1ft / 0.1ft
• 0.1m / 0.01m
Default : The “Distance” settings are returned to the default settings.
• Yes : Reset to the defaults.
• No : Do not reset to the defaults.
When you select “Default” and press ENTER ,
the “Return all settings to the default?”
prompt is displayed. Select either “Yes” or
“No”, and press
ENTER .
Front L / Front R / Center / Subwoofer / Surround L / Surround R /
Surr.Back L
z / Surr.Back R z / F.Height L / F.Height R / F.Wide L /
F.Wide R : Select the speaker.
z When the “Speaker Config.” – “Surr.Back” setting ( vpage 107 ) is
set to “1spkr”, “Surr.Back” is displayed.
• 0.0ft – 60.0ft / 0.00m – 18.00m : Set the distance.
• The speakers that can be selected differ depending on the “Amp Assign”
( vpage 106 ) and “Speaker Config.” ( vpage 106 ) settings.
• Default settings :
Front L / Front R / Center / Subwoofer / F.Height L / F.Height R / F.Wide L /
F.Wide R : 12.0 ft (3.60 m)
Surround L / Surround R / Surr.Back L / Surr.Back R : 10.0 ft (3.00 m)
• Set the difference in the distance between the speakers to less than
20.0 ft (6.00 m).
NOTE
Speakers set to “None” in “Speaker Config.” ( vpage 106 ) are not
displayed.
Setting items Setting details
Channel Level
Set the volume of the test
tone to be the same when it
is output from each speaker. Test Tone Start : Output test tone.
• Front L / F.Height L / Center / F.Height R / Front R / F.Wide R /
Surround R / Surr.Back R z / Surr.Back L z / Surround L / F.Wide L /
Subwoofer : Select the speaker.
z When the “Speaker Config.” – “Surr.Back” setting ( vpage 107 ) is
set to “1spkr”, “Surr.Back” is displayed.
• –12.0dB – +12.0dB (0.0dB) : Adjust the volume.
• When “Channel Level” is adjusted, the adjusted values are set for all the
surround modes. To adjust the channel level separately for the different
surround modes, use the operation see
page 75 .
• You can enter this setting item immediately
after pressing AMP , then T.TONE .
NOTE
• Speakers set to “None” in the “Speaker Config.”
( vpage 106 ) settings are not displayed.
• When a headphones jack is inserted in the PHONES jack of this unit, the
“Channel Level” is not displayed.
Default : The “Channel Level” settings are returned to the default settings.
• Yes : Reset to the defaults.
• No : Do not reset to the defaults.
When you select “Default” and press ENTER ,
the “Return all settings to the default?”
prompt is displayed. Select either “Yes” or
“No”, and press
ENTER .
