Silvestri Bicam III - Manual (Page 9)

Digitar 2,8/28L
Apo Digitar 5,6/47XL
Apo Digitar 4/60N
Apo Digitar 5,6/72L
Apo Digitar 4/80N
Apo Digitar 4,5/90N
Apo Digitar 5,6/100N
Apo Digitar 5,6/120N
Apo Digitar 5,6150N
Apo Digitar 5,6/180T
Apo Digitar 5,6/80 M
Apo DIgitar 5,6/120 M
D7202
D7218
D7206
D7207
D7208
D7212
D7214
D7216
D7225
D7248
D7210
D7250
2329K
2248K
2261K
2273K
2281K
2291K
2214K
2212K
2215K
2284K
2282K
2213K
2329KS
2248KS
2261KS
2276KS
2281KS
2291KS
2214KS
2212KS
2215KS
2284KS
2282KS
2213KS
Copal 0 Prontor
Magnetic Schneider
Electronic Schneider
Digital Lenses in Bayonet
How to attach the back
extension rings
table 2
Bicam back ring Seen in the photo is the rapid
4-point mounting system with 8° rotation.
Mounting a back attachment on the Bicam. After
lining up the two red spots, insert the space ring
then turn clockwise by 8°. All the other attachments
are mounted using this same system.
WARNINGS
The space rings given in the table 1 must be used. When carrying out one offset
on the camera body and another on the shift space ring, the offsets must never
contradict each other. This can cause unpleasant mechanical vignettings.
Beyond the standard extension rings, there are two
shiftable rings 15+15mm: n°1 and n°2, these rings
are used in combination with the suitable lenses (see
lens combination table 1). The shift space rings can be
used to increase the width of offset, adding to the offset
of the camera body. A scale on its side shows the extent
of offset. The two offsets must always consider the
limits covered by the lens in use (see pages 10 - 11).
HR Digaron S 4,5/28mm
HR Digaron W 4,0/32mm
HR Digaron S 4/35mm
HR Digaron W 4,0/40mm
HR Digaron W 4,0/50mm
HR Digaron S 4/60mm
HR Digaron W 5,6/70mm
HR Digaron W 5,6/90mm
HR Digaron S 4/100mm
Apo Sironar Digital 4,5/45mm
Apo Sironar Digital 4,5/55mm
Apo Sironar Digital 5,6/70mm
Apo Sironar Digital 5,6/90mm
Apo Sironar Digital 5,6/105mm
Apo Sironar Digital 5,6/135mm
Apo Sironar Digital 5,6/150mm
Apo Macro Sironar 5,6/120mm
D7226
D8032
D7228
D7448
D7450
D7234
D7231
D7237
D7239
D7230
D7232
D7233
D7238
D7240
D7242
D7244
D7246
2234K
3232K
2236K
2346K
3250K
2266K
2278K
2295K
2268K
2245K
2255K
2276K
2293K
2205K
2217K
2218K
2221K
Copal 0 Prontor
Magnetic Rodenstock
