LINKAGE PARTS LIST
REF#
PART#
DESCRIPTION
QUANTITY
1
60-106
Control Lever
1
34-021
Linkage Rod
1
HN-516-24
Nut
5
/
16
- 24
1
2
30-153
Center Console
1
3
42-766
Throttle Bracket
1
4
30-027
Relay Plate
1
5
HSTP-516-18-075
Phillips Machine Screw
5
/
16
-18 x
3
/
4
4
HNFL-516-18
Flange Whiz Lock Nut
5
/
16
-18
4
6
10-163
Forward Foot Pedal
1
48-066
Pedal Grip
1
7
15-015
Pedal Pad
1
8
16-062
Pedal Pad Plate
1
HB-38-16-125
Bolt
3
/
8
-16 x 1
1
/
4
1
9
76-296
Pedal Mount
2
18-234
Bushing
4
HG-14-28-180
Grease Zerk
2
10
31-050
Reverse Pedal
1
11
21-462
Ball Joints
6
HN-516-24
Nut
5
/
16
- 24
6
12
31-054
Pedal Rod
2
13
10-178
Relay
1
18-234
Bushing
2
HG-14-28-180
Grease Zerk
1
14
31-055
Linkage Rod
1
15
15-692
Pedal Relay
1
16
13-632
Push Pull Cable
1
17
30-159
Spray Boss Arm
1
18
30-152
Push-Pull Cable
1
19
HB-516-18-100
Bolt
5
/
16
-18 x 1
1
HW-516
Washer
4
HNTL-516-18
Lock Nut
5
/
16
-18
1
20
11-103
Linkage Yoke
1
HN-516-24
Nut
5
/
16
- 24
1
21
8-701
Ball Joint
2
HN-14-20
Nut
1
/
4
- 20
2
