Par
ts
51
30-101 EATON MOTOR PARTS LIST
REF#
PART#
DESCRIPTION
QUANTITY
1
30-101-01
Shaft and Bearing Kit (7/8 splined 13T)
1
2*
Seal
4
3*
Exclusion Seal
1
4*
Shaft Seal
1
5*
Back Up Ring
1
6
30-101-02
Bearing Housing
1
7*
Shaft Face Seal
1
8
30-101-03
Wear Plate
1
9
30-101-04
Main Drive
1
10
30-101-05
Geroler
1
11
30-101-06
Valve Plate
1
12
14-207
Valve Drive
1
13
14-208
Valve
1
14
30-101-07
Balance Ring
1
15
14-210
Balance Ring Pin
2
16
14-209
Compression Spring
2
17*
Inner Face Seal
1
18*
Outer Face Seal
1
19
30-101-08
Valve Housing
1
20
30-101-09
Plug Assembly
1
*
O-ring
1
21
30-101-10
Cap Screw
4
*
30-101-11
Seal Kit
1 per
