• Color Temp is used to control color temperature. (User, Normal, Warm, Cool)
• Alarm is input for the alarm level (Max 5 Vdc) of sensor or any alarm device.
- Alarm menu (pull-down menu)
Enable is used ON or OFF the alarm function.
Alarm
Enable < On >
Source
< CVBS1 >
Time < 10 >
Option < N.O. >
Buzzer < OFF >
Volume
40
Display Type < FULL >
Source select the input source the alarm screen.
Time is used to adjust the alarm view time.
Option selects the N.O. or N.C. mode.
Buzzer is used ON or OFF the alarm sound function.
Volume is used to adjust the buzzer value.
Display Type change the Alarm display type.
(Full or PIP&Full Mode)
Note: Alarm that fit the N.O. or N.C. case an endless loop.
• Energy Saving change the Display Backlight. (OFF, Medium, Maximum) (27” only)
When decreasing the backlight, the brightness of the black becomes darker without any loss in
video signal and the power consumption is reduced.
• 3D NR disable.
• Anti Burn disable.
• Recall the monitor original factory setting.
• Source selects between the CVBS (Composite INPUT), S-Video (Super Video INPUT),
RGB (PC INPUT), DVR, DVI or HDMI to be displayed.
● OSD Menu
11
OSD Menu
Language < English >
H Position
V Position
Blending
Time < 45 >
• Language change the OSD language according to personal preference.
• H Position is used to adjust the horizontal position of the Menu window on the screen.
• V Position is used to adjust the vertical position of the Menu window on the screen.
• Blending is used adjust the opaqueness of the background of the OSD.
• Time is used to adjust the OSD view time.
●PIP Menu
• Multi Window is change the display type. (PIP / PBP 4:3 / PBP Full)
PIP
Multi Window OFF >
Sub Source < CVBS1 >
Size
Small >
Position < U_L >
• Sub Source select the input source the sub screen.
• Size select the PIP sub screen display size. (Small / Middle / Large)
• Position adjust the PIP sub screen display position. (U_L / D_L / D_R / U_R)
