135
NV9649
User’s Guide
Environmental Specifications
Table provides environmental specifications for the NV9649.
Defaults
Initial Panel State
Destination: the configured default.
Buttons: low-tally is 40% brightness by default and stays at its most recent setting.
Configuration Page
The initial NV9649 configuration has no buttons defined. The default panel options are:
Behavioral model: LCD XY/MD mode.
Default mode: Multi-destination mode.
Release mode: Normal.
Default destination: None.
Preset monitor: None
Status monitor: None
Data routing: Automatic.
Salvo list: None
Default name set: System names
Use continuous scroll:Enabled (check box checked)
Other options: All disabled (check boxes clear) except ‘Src/Dst Immediate Take’.
The tally inputs and outputs are all initially undefined.
DHCP
The panel is set up to respond to DHCP from the factory. It is possible to assign the panel a fixed
IP address using the Panel IP Configuration Utility.
NV9649 Environmental Specifications
Specification Detail
Operating temperature 0–40°C, ambient.
Relative humidity 0 to 90%, non-condensing.
Cooling No fan required.
