Commissioning and preparing to measure
Network configuration
76 Operating Instructions
Configure additional
modules MSE 1000 modules must be configured one at a time when configuring the module
chain manually.
To configure additional modules:
Turn the power off.
Install the next module into the module chain.
Turn the power on.
Wait for the Network LED to flash twice per second on all modules.
Perform a broadcast. Refer to Broadcast"", page 67.
If the new module is configured to use DHCP addressing (default) a dialog box will
appear asking to configure the new module to use static addressing.
Click the «OK» button to switch to static addressing.
A dialog box confirms the module has been configured to use static addressing.
Cycle the power. Turn the power off, wait 20 seconds then turn the power on.
Wait for the Network LED to flash twice per second on all modules.
Click the «OK» button in the dialog box.
A dialog box displays the number of modules found.
Click the «OK» button to overwrite the configurable module settings from a backup
file or click the «Cancel» button to proceed without overwriting the settings.
Assign the new module a unique static IP address.
Repeat this process until all required modules are configured into the module chain.
