9.2 The PLANE Function: Tilting
the Working Plane
(Software Option 1)
Introduction
The PLANE function is a powerful function for defining tilted working
planes in various manners.
All PLANE functions available on the TNC describe the desired working
plane independently of the rotary axes actually present on your
machine. The following possibilities are available:
The machine manufacturer must enable the functions for
tilting the working plane!
You can only use the PLANE function on machines which
have at least two rotary axes (head and/or table).
Exception: PLANE AXIAL can also be used if only a single
rotary axis is present or active on your machine.
Function Required parameters Soft key Page
SPATIAL Three space angles: SPA,
SPB,
and SPC
Page 489
PROJECTED Two projection angles:
PROPR
and PROMIN and a
rotation angle ROT
Page 491
EULER Three Euler angles:
precession (EULPR),
nutation (EULNU) and
rotation (EULROT) Page 493
VECTOR Norm vector for defining
the plane and base vector
for defining the direction of
the tilted X axis Page 495
POINTS Coordinates of any three
points in the plane to be
tilted Page 497
RELATIVE Single, incrementally
effective space angle Page 499
