Fundamentals
TNC model, software and features
18
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
New and modified cycle functions 34059x-05
New cycle
880 (Option #50), see "ZAHNRAD ABWÄLZFRÄSEN
(Zyklus 880, DIN/ISO: G880)"
New cycle
292 (Option #96), see "INTERPOLATIONSDREHEN
KONTURSCHLICHTEN (Zyklus 292, DIN/ISO: G292, Softwareoption
96)"
New cycle
291 COUPLG.TURNG.INTERP. (Option #96), see
"INTERPOLATIONSDREHEN KOPPLUNG (Zyklus 291, DIN/ISO:
G291, Softwareoption 96)"
New cycle
239 for LAC (Load Adapt. Control) load-dependent
adaptation of control parameters (Option #143), see "BELADUNG
ERMITTELN (Zyklus 239 DIN/ISO: G239, Software-Option 143)"
Cycle
270 CONTOUR TRAIN DATA has been added (Option #19),
see "KONTURZUG-DATEN (Zyklus 270, DIN/ISO: G270, Software-
Option 19)"
Cycle
39 has been added (Option #1), see "ZYLINDER-MANTEL
(Zyklus 39, DIN/ISO: G139, Software-Option 1)"
The character set of machining cycle
225 has been expanded
with the CE character, ß, the @ character and system time, see
"ENGRAVING (Cycle 225, DIN/ISO: G225)"
Cycles
252-254 have been expanded with the optional parameter
Q439
Cycle
22 has been expanded with the optional parameters Q401,
Q404, see "ROUGHING (Cycle 22, DIN/ISO: G122, software option
19)"
Cycle
484 has been expanded with the optional parameter Q536,
see "Calibrate the wireless TT 449 (Cycle 484, DIN/ISO: G484,
software option 17 Touch Probe Functions software option 17)"
Cycles
841 SIMPLE REC. TURNG., RADIAL DIR., 842 , 851 , 852
have been expanded with plunge feed rate Q488
Eccentric turning with cycle
800 is possible with Option #50, see
"ADAPT ROTARY COORDINATE SYSTEM(Cycle 800, DIN/ISO:
G800)"
