Programming: Tools
5.2 Tool data
5
184
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
Selecting a pocket table in the Programming mode of
operation
Call the File Manager
Display the file types: Press the
SHOW ALL soft
key
Select a file or enter a new file name. Conclude
your entry with the
ENT key or the SELECT soft
key
Abbr. Inputs Dialog
P
Pocket number of the tool in the tool magazine -
T
Tool number
Tool number?
RSV Pocket reservation for box magazines Pocket reserv.: Yes =
ENT / No = NOENT
ST Special tool ( ST ); If your special tool blocks pockets in front of
and behind its actual pocket, these additional pockets need to
be locked in column L (status L).
Special tool?
F
The tool is always returned to the same pocket in the tool
magazine
Fixed pocket? Yes =
ENT / No = NO ENT
L Locked pocket (see also column ST) Pocket locked Yes =
ENT / No = NO ENT
DOC Display of the comment to the tool from TOOL.T -
PLC
Information on this tool pocket that is to be sent to the PLC
PLC status?
P1 ... P5
Function is defined by the machine tool builder. The machine
tool documentation provides further information
Value?
PTYP
Tool type. Function is defined by the machine tool builder. The
machine tool documentation provides further information
Tool type for pocket
table?
LOCKED_ABOVE Box magazine: Lock the pocket above Lock the pocket
above?
LOCKED_BELOW Box magazine: Lock the pocket below Lock the pocket
below?
LOCKED_LEFT
Box magazine: Lock the pocket at left
Lock the pocket at
left?
LOCKED_RIGHT
Box magazine: Lock the pocket at right
Lock the pocket at
right?
