Functions of the TNC 640 and the iTNC 530 compared 19.5
19
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 1/2015
701
Function TNC 640 iTNC 530
PLANE function :
TABLE ROT/COORD ROT not
defined Configured setting is used COORD ROT is used
Machine is configured for axis
angle All PLANE functions can be
used
Only PLANE AXIAL is executed
Programming an incremental
spatial angle according to
PLANE AXIAL Error message is issued Incremental spatial angle is
interpreted as an absolute
value
Programming an incremental
axis angle according to
PLANE
SPATIAL if the machine is
configured for spatial angle
Error message is issued Incremental axis angle is
interpreted as an absolute
value
Programming of
PLANE
functions with active Cycle 8
MIRROR IMAGE
Error message is issued
PLANE AXIAL is possible Function is available with all
PLANE functions
Special functions for cycle
programming:
FN17 Function available, details are
different Function available, details are
different
FN18 Function available, details are
different Function available, details are
different
Compensation of tool length in the
position display The tool length entries
L and DL
from the tool table are taken into
account in the position display,
from
TOOL CALL depending
on the machine parameter
progToolCallDL
The tool length entries
L and DL
from the tool table are taken into
account in the position display
Comparison: Differences in MDI operation
Function TNC 640 iTNC 530
Execution of connected
sequences Function partially available Function available
Saving modally effective functions Function partially available Function available
