Example: Drilling in the W axis
0 BEGIN PGM PAR MM
1 BLK FORM 0.1 Z X+0 Y+0 Z-20
2 BLK FORM 0.2 X+100 Y+100 Z+0
3 TOOL CALL 5 Z S2222
Call the tool in the spindle axis Z
4 L Z+0 W+0 R0 FMAX M91
Reset the principle axis and minor axis
5 L Z+100 R0 FMAX M3
Position the principal axis
6 CYCL DEF 200 DRILLING
Q200=+2
;SET-UP CLEARANCE
Q201=-20
;DEPTH
Q206=+150
;FEED RATE FOR PLNGNG
Q202=+5
;
Q210=+0
;DWELL TIME AT TOP
Q203=+0
;SURFACE COORDINATE
Q204=+50
;2ND SET-UP CLEARANCE
Q211=+0
;DWELL TIME AT DEPTH
Q395=+0
;DEPTH REFERENCE
7 FUNCTION PARAXCOMP DISPLAY Z W
Activate display compensation
8 FUNCTION PARAXMODE X Y W
Positive axis selection
9 L X+50 Y+50 R0 FMAX M99
Infeed runs minor axis W
10 FUNCTION PARAXMODE OFF
Restore standard axis configuration
11 L Z+0 W+0 R0 FMAX M91
Reset the principle axis and minor axis
12 L M30
13 END PGM PAR MM
