SPARE PARTS LIST LISTA PARTI DI RICAMBIO TEILELISTE
LISTE DES PIÈCES LISTA DE PIEZAS
PART. DESCRIPTION PART. DESCRIPTION
AR 1 Lower housing AR 24 Anti rotation gaskets
AR 2 Bumper AR 25 Filter grill
AR 3 Lower handle AR 26 Hook kit bag cover
AR 4 Wheel kit AR 27 Exhaust carbon/microfilter
AR 5 Circuit board Red , Elite AR 28 Hook access. Cover Kit
AR 5 Circuit board Platinum AR 29 Motor housing filter
AR 6 Lower parking support AR 30 Crevice tool
AR 7 Hepa filter AR 31 Upholstery tool
AR 8 Exhaust filter cover AR 32 Swivel round dust
AR 9 Buttons kit +, - AR 33 Tool cover
AR 10 Vacuum motor with gasket AR 34 Spring tool cover
AR 11 Bag support kit AR 35 Display (Aria, Elite)
AR12 Motor protection filter AR 36 Display cover (Aria, Elite)
AR12 Motor protection carbon active filter AR 37 Adjusting knob
AR 13 Wire kit with connector AR 38 Display (Platinum)
AR 14 Motor housing AR 39 Display cover (Platinum)
AR 15 Vacuum sensor cpl. AR 40 Housing motor prot. filter
AR 16 Plug stop plate AR 41 Screw 3,9 x 13 (20pcs.)
AR 17 Cord winder EU, USA plug AR 42 Screw 3,9 x 16 (20 pcs.)
AR 18 Bag housing cover AR 43 Screw 3,9 x 19 (20 pcs.)
AR 19 Lever n°2 pcs. AR 44 Screw 3,9 x 22 (20 pcs.)
AR 20 Upper handle AR 45 Screw 3,9 x 45 (20 pcs.)
AR 21 Upper housing AR 47 Screw 3,5 x 13 (20 pcs.)
AR 22 Main switch AR 48 Flexible hose complete
AR 23 Foot pedal kit (2pcs.) AR 48 Electrified hose complete
Aria Aria elite Aria Platinum
SPARE PARTS LIST - LISTA PARTI DI RICAMBIO
LISTE DER ERSATZTEILE- LISTE PIÈCES DE RECHANGE –
LISTA PIEZAS DE RECAMBIO
Technical improvements
Lindhaus reserves the right to make technical improvements and modifications without prior notice. For this reason, the appliance can deviate in details from the leaflet information.
Migliorie tecniche
Lindhaus si riserva il diritto di apportare delle migliorie tecniche e delle modifiche senza preavviso. In tal caso alcuni dettagli potranno non risultare conformi alle informazioni riportate sulla documentazione tecnica.
Technische Verbesserungen
Lindhaus behält sich technische Verbesserungen im Rahmen der Modellpflege vor. Daher kann das Gerät in Details von Prospektangaben abweichen.
Perfectionnements techniques
Lindhaus se réserve le droit de procéder à des perfectionnements techniques dans le cadre de la gestion de ses modèles. Certains détails de la machine peuvent ainsi différer des données indiquées dans le prospectus.
Mejoras técnicas
Lindhaus reserva el derecho a hacer cualquier modificatión y arreglo técnico sin previo aviso. Por esta razón, los detalles acerca de la maquina podrían resultar diferentes de las informaciones indicadas en el manual de
información.
12
