10
Modes of Operation
3G Communication Only (without IP Cameras or WiFi)
After the router-mounting board assembly has been installed, do the
following:
1. Use an Ethernet cable to connect the router to the IP module.
2. Connect the power adapter cord to the router’s micro-USB port,
with the other end of the cord routed through the opening on the
back of the main panel/Plastic Accessory Box (together with the
Ethernet cable if applicable).
3. Close up the main panel/ Plastic Accessory Box, connect the other
end of the cord to the power adapter, and plug the power adapter
into an electrical socket; a blue Network Status LED on the router
indicates successful 3G network connectivity (see LED Indicators,
page 15).
Options for use with IP Cameras
IP cameras can be used in the system as follows:
• Using IP cameras in a wireless (WiFi) network configuration:
The router connects to the IP module on the main panel, and the
IP cameras are connected via WiFi.
• Using IP cameras in a wired (LAN) configuration: Any standard
10/100 multi-port Ethernet switch is needed (for example, an
8-port switch) which connects to each IP camera, the IP module,
and the router.
