9
Installing in the Plastic Accessory Box
The RP128B50000A “B5” Plastic Accessory Box can be used with
Agility, or with other RISCO systems – and is necessary for systems
that have the main panel in a metal enclosure.
The side of the router with the micro-USB port (for the power
adapter cable) should be affixed within 15 mm—18 mm from the
upper edge of the mounting board:
NOTE: The router can be installed at one of the two locations (left
or right side) that are used for installing the 8-zone expander.
Ethernet cable
Power adapter cable (micro-USB)
