7
Installing the Router-Mounting Board Assembly
The mounting board holds the router inside the Plastic Enclosure or
Plastic Accessory Box. The router is fastened onto the mounting
board with the provided ultra-strong adhesive strips.
NOTE: The router should not be installed inside a metal enclosure.
IMPORTANT: Due to clearance limitations for the cables in the
Plastic Enclosure and Plastic Accessory Box, it is recommended to
install the router as follows:
1. First attach the power cable and Ethernet cable to the router.
2. Then install only the mounting board onto the enclosure/box. For
the Plastic Enclosure, install onto the 2 standoffs (see page 8), and
for the Plastic Accessory Box, install using the provided screws
(see page 9).
3. Place the adhesive strip on the back side of the router.
4. Carefully position the router onto the mounting board, making
sure the power adapter and Ethernet cables both have enough
room for clearance and routing, and so the enclosure/box cover
can be closed – for the Plastic Enclosure, see the guidelines on
page 8, and for the Plastic Accessory Box, see the guidelines
on page 9.
NOTE: The adhesive strip has a very strong bond and is not meant
to be removed.
NOTE: For additional details on installing the Plastic Enclosure and
Plastic Accessory Box, refer to their respective instructions.
