6. Define the following fields in the Add Camera dialog box:
Field Description
Label Enter a name for the camera
Partitions Select the partition(s) from the list of defined partitions
Type
Choose the RISCO camera type
MAC
Address
Enter the MAC address into this field. The MAC
address (media access control address) is the unique
identifier assigned to the IP camera for
communications on the physical network.
NOTE: The MAC address is case sensitive and should
be entered exactly as it is shown on the box or on the
back cover of the IP camera, e.g. AA:BB:CC:DD:EE:FF
7. Click Add.
If the “Camera was identified successfully” message is displayed, go
straight to Establishing a WiFi Connection, page 13.
If an “unable to configure Internet Access”, “UPnP Client Error” or
similar message is displayed, refer to the Troubleshooting section in
the IP Camera Installation documentation.
NOTE: This message is only relevant for IP cameras that are
physically connected to the LAN network via the router.
Establishing a WiFi Connection
 To establish a WiFi connection:
1. Select Connect to WiFi to establish a wireless network connection;
a list of available wireless networks is displayed.
2. Select your wireless network from the list and click Connect.
NOTE: If your network is password protected, the password
must be entered into the displayed password screen.
