Setting the Menu
35
Setting the Menu
1. Press the [AUTO PITCH], [HARMONY] and [VOCODER] buttons at the same time.
The unit enters menu mode.
2. Use the buttons and sliders to make the settings.
For details, refer to the parameters below.
3. When you are finished, press the [AUTO PITCH], [HARMONY] and [VOCODER] buttons at the same time.
System settings
Item Controller Value Explanation
USB OUT
ROUTING
[AUTO PITCH] button
NIX.O, NIC.I
(Mix Out, Mic In)
Sets whether to use the output audio from your computer or
tablet for the MIC IN input (
NIC.I ) or for the MIX OUT input
(
NIX.O
).
FORCE
HEADSET
[HARMONY] button
Avto, Forc
(Auto, Force)
When this is set to “
Forc
”, only the headset mic is used, regardless
of whether a front mic is plugged in.
MIDI KEY IN
[VOCODER] button
Off, KeY.I
(Off, Key In)
When this is set to “ KeY.I ”, the pitch remains fixed when note
messages are input.
MIDI
THROUGH
[ ð ] (stop) button
Off, ñhrv
(Off, Through)
When this is set to “
ñhrv
”, the messages that are input from the
MIDI IN connector are output to the MIDI OUT connector.
AIRA LINK
(*1)
[ в / у ] (play/record) button
Off, A.Lnk
(Off, AIRA Link)
Set this to “ A.Lnk ” when connecting a device via USB that is
compatible with AIRA LINK, such as the MX-1.
Otherwise, leave this at the “
Off
” setting.
The setting takes effect after the unit is powered off and on again.
MIDI
CHANNEL
[SCATTER] dial
Ch.1 – Ch.16
Specifies the MIDI transmit/receive channel.
SYNC
CLOCKS
[PITCH] slider
1, 2, 3, 4,
6, 8, 12, 24
Sets the number of sync clocks per beat.
SYNC RATE
[FORMANT] slider
1_8, 1_4,
1_2, 1
(1/8, 1/4, 1/2, 1)
Sets the synchronization cycle for the looper.
