69 Solo
Operating Instructions
7. Parts & Assembly
AS2833 SOLO R REAR DRAWBAR
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P00003 BOLT M12x40 GR. 8.8 4
2 P00203 ADAPTOR MALE-MALE ½" BSP 4
3 P00774 SHUT OFF TAP ½" BSP 4
4 P00941 BOLT M30x90 GR. 8.8 4
5 P01224 BOLT M20x180 GR. 8.8 2
6 P01901 BOLT M16x80 GR. 8.8 4
7 P02007 NUT LOCK M12 4
8 P02008 NUT LOCK M16 4
9 P02009 NUT LOCK M20 2
10 P02011 NUT LOCK M30 4
11 P02263 DOWTY SEAL ½" BSP 12
12 P02484 LYNCH PIN CAT 2 1
13 P02600 WASHER FLAT M10 4
14 P02601 WASHER FLAT M12 8
15 P02602 WASHER FLAT M16 8
16 P02603 WASHER FLAT M20 4
17 P02608 WASHER FLAT M30 4
18 P02730 QUICK RELEASE FEM. ½" BSP 4
19 P02735 BULKHEAD ½" BSP 4
20 P05534 NUT LOCK M10 4
21 P05796 REFLECTOR - RED 2
22 P05797 LIGHT UNIT 2
23 P05800 LIGHT PLATE 2
24 P05820 JUNCTION BOX 1
25 P06337 BULB INDICATOR LLB 335 2
26 P06338 BULB STOP/TAIL LIGHT LLB 380 2
27 P06400 BOLT M4x15 GR. 8.8 4
28 P06401 NUT PLAIN M4 4
29 P06402 WASHER FLAT M4 4
30 P07544 PLASTIC END CAP 50x50 1
31 P09055 LIGHT MOUNT 2
32 P09112 CLAMP ½" BSP PAIR 2
33 P09113 CLAMP - TOP PLATE 2
34 P09226 BOLT M10x80 GR. 8.8 4
35 P09517 PERFECT HITCH - REAR 1
36 P10235 DRAWBAR PIN Ø30 1
37 P10278 BOLT M8x45 GR. 8.8 2
38 P12424 TRAILER SOCKET FEMALE 12N 1
39 P12425 SOCKET 12N - BOOT 1
40 P12426 SOCKET 12N - INSTALL KIT 1
41 P15236 SOLO R REAR DRAWBAR 1
42 P15238 HYD. MTG PLATE 1
43 P15239 HYD/ LIGHT MTG. PLATE 1
44
45
46
47
48
49
50
