93

Solo

Operating Instructions

7. Parts & Assembly

AS0659D

SOLO 600 - MID ROLL WING RH

IT EM

PART NO

DESCRIPT ION

QT Y

COMMENT S

1

P00071

NIPPLE - GREASE

3

2

P00983

BOLT M30x150 GR. 8.8

1

3

P01645

BUSH SPRUNG - Ø32xØ26x32

2

4

P02010

NUT LOCK M24

4

5

P02011

NUT LOCK M30

1

6

P02604

WASHER FLAT M24 Ø50

6

7

P02608

WASHER FLAT M30

2

8

P04025

BOLT M24x90 GR. 8.8

4

9

P05492

NUT LOCK 1" UNF

1

10

P05567

BOLT 1" UNFx5" GR. V

1

11

P07361

GREASE NIPPLE 45°

2

12

P09018

WING CARRIER REAR RH MID ROLL

1

13

P09035

RAM POINT BOLT ON

1

14

P09093

SHIM - 2mm

3

15

P09106

SHIM - 3mm

3

16

P10636

BUSH SPRUNG - Ø40xØ31x20

2

17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
