TOYOTA 2010 Prius User Manual
Page 489
466
4-3. Do-it-yourself maintenance
FUSE
Ampere
Circuit
12
AM2
7.5A
Power windows
13
ECU-B2
7.5A
Smart key system
14
MAYDAY
10A
No circuit
15
ECU-B3
10A
Air conditioning system
16
TURN & HAZ
10A
Turn signal lights
17
ETCS
10A
Multiport fuel injection system/
sequential multiport fuel injection
system
18
ABS MAIN
NO.1
20A
Anti-lock brake system
19
P/I 2
40A
Parking control system, horn,
right-hand headlight (low beam),
left-hand headlight (low beam),
back-up lights
20
ABS MTR 1
30A
Anti-lock brake system
21
ABS MTR 2
30A
Anti-lock brake system
22
H-LP HI MAIN
20A
H-LP HI RH, H-LP HI LH,
headlight switch, daytime running
light system
23
P/I 1
60A
IG2, EFI MAIN, BATT FAN
24
EPS
60A
Electric power steering
25
PCU
10A
Inverter and converter
26
IGCT NO.2
10A
Hybrid system, parking control
system, power windows, inverter
and converter
