467
4-3. Do-it-yourself maintenance
4
Mainten
ance an
d ca
re
FUSE Ampere Circuit
27 MIR HTR 10A Outside rear view mirror defoggers
28 RAD NO.1 15A Audio system, navigation system
29 DOME 10A
Door courtesy lights, personal
lights, interior lights, front foot
lights, vanity lights, inside rear
view mirror, garage door opener,
electric power steering
30 ECU-B 7.5A
Smart key system, multiplex com-
munication system, personal
lights, gauges and meters
31 H-LP LH HI 10A Left-hand headlight (high beam)
32 H-LP RH HI 10A Right-hand headlight (high beam)
33 EFI NO.2 10A
Multiport fuel injection system/
sequential multiport fuel injection
system
34 IGCT NO.3 10A Cooling system
35 SPARE 30A Spare fuses
36 SPARE 15A Spare fuses
37 SPARE 7.5A Spare fuses
38 EFI MAIN 20A
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO.2
39 BATT FAN 10A Battery cooling fan
40 IG2 20A
Multiport fuel injection system/
sequential multiport fuel injection
system, MET-IGN, IGN, power
windows
