Outside temperature display
You should pay special attention to road
conditions when temperatures are around
freezing point.
The outside temperature display is in the
multifunction display (
Y page 222).
Changes in the outside temperature are
displayed after a short delay.
Speedometer with segments
The segments in the speedometer indicate
which speed range is available.
R
Cruise control activated ( Y page 173):
The segments light up from the stored
speed to the maximum speed.
R
DISTRONIC PLUS activated ( Y page 175):
One or two segments in the set speed
range light up.
R
DISTRONIC PLUS detects a vehicle in front:
The segments between the speed of the
vehicle in front and the stored speed light
up.
Operating the on-board computer
Overview
The on-board computer is activated as soon
as you turn the SmartKey to position
1 in the
ignition lock.
You can control the multifunction display and
the settings in the on-board computer using
the buttons on the multifunction steering
wheel.
:
Multifunction display
;
Switches on the Voice Control System;
see the separate operating instructions
=
Right control panel
?
Left control panel
A
Back button
Left control panel
=
; R
Calls up the menu and menu bar
9
: Press briefly:
R
Scrolls in lists
R
Selects a submenu or function
R
In the Audio menu: selects a
stored station, an audio track or
a video scene
R
In the Tel (telephone) menu:
switches to the phone book and
selects a name or telephone
number
Displays and operation
221
On-board computer and displays
Z
