18
EDID LEARNING
The EDID learning function is only necessary whenever you encounter any display connected to
the HDMI
™
output port that cannot play audio and video properly. Because the HDMI
™
source
devices and displays may have various level of capability in playing audio and video, the general
principle is that the source device will output the lowest standards in audio format and video
resolutions to be commonly acceptable among all HDMI
™
displays. In this case, a 720p stereo
HDMI
™
signal output would be probably the safest choice. Nevertheless, the user can force the
matrix to learn the EDID of the lowest capable HDMI
™
display among others to make sure all
displays are capable to play the HDMI
™
signals normally by performing the procedures stated
below.
SW1-SW8 Pin-1 must be set “ON” for EDID Learning Mode
DIP Switch
Position
Video
Audio
Description
Pin-1
ON
[ª]
Bypass Stereo EDID Learning – for learning EDID from the receiver
Method 1: Manually connect HDMI
™
displays to HDMI
™
input ports
1. Power up the matrix master unit. Connect the HDMI
™
display that its EDID needs to be
learned to any of the HDMI
™
INPUT1-INPUT8
port where your source device has trouble to
show the picture normally.
2. To learn the display’s EDID for source device connected to respective HDMI
™
INPUT1-
INPUT8 port, pull both pins of respective DIP switch SW1-SW8 up-and-down to stay at
ON[ª]-ON[ª] and wait for about 5 seconds to complete the EDID learning process. You
DON’T NEED to pull up the DIP switch again unless you want to learn another display’s EDID
by pulling both DIP switch pin-1 & pin-2 of SW1-SW8 up-and-down one more time.
3. Repeat step1 & step2 if you want to learn the EDID of this HDMI
™
display on any other HDMI
™
input ports that have same trouble playing the audio/video properly.
Method 2: Use the front panel of the master unit
Button
Function
Output Port
EDID will be read from display via the connected receiver unit from the
respective output port
Input Channel
The EDID will be sent to the input source connected to respective HDMI
™
input port
