21
Custom Code — IR4 Code: 0x13 0x31
Custom Code: 0x13 0x31
Output 1 Output 2 Output 3 Output 4 Output 5 Output 6 Output 7 Output 8
Source 1 0xAE 0xBE 0xCE 0xDE 0xEE 0xFE 0x1E 0x2E
Source 2 0xAD 0xBD 0xCD 0xDD 0xED 0xFD 0x1D 0x2D
Source 3 0xAC 0xBC 0xCC 0xDC 0xEC 0xFC 0x1C 0x2C
Source 4 0xAB 0xBB 0xCB 0xDB 0xEB 0xFB 0x1B 0x2B
Source 5 0xAA 0xBA 0xCA 0xDA 0xEA 0xFA 0x1A 0x2A
Source 6 0xA9 0xB9 0xC9 0xD9 0xE9 0xF9 0x19 0x29
Source 7 0xA8 0xB8 0xC8 0xD8 0xE8 0xF8 0x18 0x28
Source 8 0xA7 0xB7 0xC7 0xD7 0xE7 0xF7 0x17 0x27
Note: Using terminal to set Custom Code
Example: Set custom code from 0x01 0xEE to 0x13 0x31
>>IR4 -------------- command (using RS-232 terminal command mode)
>>IR4 -------------- echo
Command Custom Code
IR2 0x00 0xFF
IR3 0x12 0x21
IR4 0x13 0x31
For further information, please check the installation CD.
